Function
Generator Using Operational Amplifier
Copyright©2019 | Lab developed by Virtual Labs, IIT Roorkee
Instructions:
- Click on 'Power Off' button to start the experiment.
- Vary the Amplitude, Frequency, Phase using the range sliders.
- Click on 'Dual' button to observe all the three waveforms.
- 'Channel' 1 shows the sine waveform, 'Channel 2' shows the triangle waveform and 'Channel 3'
shows
the square waveform.
- You can also position the waveforms on the graph using the positioning range sliders.
